Chapter 1 Introduction; Overview - GeoVision GV-IP Speed User Manual

Chapter 1 Introduction

1.1 Overview

To meet different needs, the GV-IP Speed Dome is offered in two types: indoor and outdoor.
Through both web-based configurations, it is easy to configure and manage the GV-IP Speed
Dome.
The GV-IP Speed Dome provides variable pan/tilt speeds ranging from a fast patrol of 400°
per second to a slow ramble of 5° per second with 0.225° pan accuracy for fast and accurate
tracking ability. The 360° endless rotation and -10°~190° tilt travel make tracking the object
passing directly beneath the GV-IP Speed Dome. A maximum of 256 preset points can be
programmed for precise location of target areas, and users can also define 8 sequences, 4
auto-pan modes and 4 cruise routes for the Dome to operate automatically.
The GV-IP Speed Dome provides 4 alarm inputs and 1 alarm relay output, and the alarm
management can be done through the network as well.
Features:
• 18x, 23x, 36x optical zoom
• CIF and D1 resolution
• H.264, MPEG 4 and MJEPG video compression
• BNC out, 2-way audio
• 4 digital inputs, 1 relay output
• Preset speed up to 400°/sec
• Auto calibration
• Digital image flip
• Minimum illumination 0.01 lux (B/W)
• Wide dynamic range
1 Introduction
1
