1.4 Functional Panel

1.4.1

GV-IP Speed Dome of Indoor Type

No. Name
1 Reset
2 Default
3 Ethernet
4 22-Pin Connector
5 Communication Switch
6 Reserved (for hardware firmware upgrade)
Figure 1-1
Function
Resets the GV-IP Speed Dome and keeps all
current configurations.
Restores all the settings, except PTZ settings, to
the factory default values. For details see 6.3
Restoring to Factory Default Settings.
A plug for inserting an Ethernet cable to build the
network connection.
For details, see 1.6 22-Pin Data Cable.
For details, see 1.5 Communication Switch.
