1.4.2 GV-IP Speed Dome of Outdoor Type

No. Name
1 Reset
2 Default
3 22-Pin Connector
4 Ethernet
5 Communication Switch
6 Reserved (for hardware firmware upgrade)
6
Figure 1-2
Function
Resets all configurations of GV-IP Speed Dome.
Restores all the settings, except PTZ settings, to
the factory default values. For details see 6.3
Restoring to Factory Default Settings.
For details, see 1.6 22-Pin Data Cable.
A plug for inserting an Ethernet cable to build the
network connection.
For details, see 1.5 Communication Switch.
