GeoVision GV-IP Speed User Manual page 25

81-D7H06-HCM Hard Ceiling Mount
81-D7H06-TBC T-Bar Ceiling Mount
81-DH701-S01
81-DH801-S01
81-P1030-001
(Input: 110 -115V AC)
81-P2030-001
(Input: 220 -230V AC)
Note:
1. The Hard Ceiling Mount is a standard accessory for the Dome of indoor type. You may
purchase the Mount optionally.
2. For details on Power Box, see 10. Optional Power Box.
5.4" Smoke Cover
5.8" Smoke Cover
Power Box
Power Box
Indoor use only (see Note later)
Height: 21.4 mm / 0.84 in
Diameter of the three holes: 4.5 mm / 0.17 in
Diameter of the bracket: 158 mm / 6.22 in
Supplied with Fixing Plate and Red Sticker
Indoor use only
Height: 160 mm / 6.3 in
Diameter: 180 mm / 7.1 in
Weight: 0.5 kg / 1.1 lb
Indoor use only
Diameter: 137 mm / 5.4 in
Outdoor use only
Diameter: 145 mm / 5.7 in
Outdoor use only (see Note later)
Dimensions (L x W):
185.5 x 147 mm / 7.3 x 5.8 in
Weight: 2.6 kg / 5.8 lb
Output: 24VAC 72VA
Weatherproof (IP66)
Outdoor use only (see Note later)
Dimensions (L x W):
185.5 x 147 mm / 7.3 x 5.8 in
Weight: 2.6 kg / 5.8 lb
Output: 24VAC 72VA
Weatherproof (IP66)
