Communication Switch - GeoVision GV-IP Speed User Manual

1.6

Communication Switch

You can find the Communication Switch below in both indoor and outdoor types of GV-IP
Speed Domes.
SW 1
SW 2
SW 3
SW 4
SW 5
SW 6
SW5 is used to restore all the PTZ settings to original default values. Follow the steps below
to restore default PTZ values:
1. Disconnect the power to the Dome.
2. Push SW5 upward to ON.
3. Reconnect the power to the Dome. The process of loading default PTZ values is complete
and you have to reset the Dome.
4. Disconnect the power to the Dome again.
5. Push SW5 downward to OFF.
6. Reconnect the power to the Dome. All the PTZ settings are returned to default values.
Note: It is recommended to use the Web interface to restore all the PTZ settings to the factory
default values. For this operation, see 4.10 System Configuration.
10
Figure 1-12
Not Functional
Default
Not Functional
