3. Type the IP address, username and password of the GV-IP Speed Dome. Modify the
default HTTP port if necessary.
4. Select GeoVision from the Brand drop-down list and select GV-SD010 from the Device
drop-down list. This dialog box appears.
Figure 7-4
Dual Stream: Click this button to set the codec type to H.264 in the main stream and
to MPEG4 in the sub stream with the resolutions listed below.
Camera
GV-SD010
Port: Modify the video streaming port number if necessary.
Stream Number: You have the option of single streaming only or both single and dual
streaming.
Codec type: You have the option of MPEG4, JPEG, or H.264. If the selected camera
supports dual streaming, the preview codec and recording codec can be set
differently.
Resolution: Select resolutions for preview and recording.
5. Click Apply. The IP camera is added to the list.
116
Resolution
Main Stream (H.264) Sub Stream (MPEG4)
704 x 480 352 x 240
