4.6 Image Setting- White Balance

The White Balance control offers different options to adjust the color ratios. On the models
GV-SD010-18X, GV-SD010-36X, GV-SD010-S18X and GV-SD010-S36X, all of the following
options are available. On the models GV-SD010-23X and GV-SD010-S23X, only Auto and
Manual are available.
Auto: The Dome automatically adjusts the color to be closest to the image you are
viewing.
Indoor: The preset White Balance value for indoor lighting.
Outdoor: The preset White Balance value for outdoor lighting.
ATW: ATW (Auto Tracing White Balance) allows the Dome to constantly adjust for optimal
color reproduction.
Manual: The White Balance values can be manually changed by moving the sliders to
adjust R Gain (red color of images) and B Gain (blue color of images) values.
Figure 4-5
PTZ OSD Control Panel
