Digital Projection M-Vision Laser 21000 WU

Electrical and physical specifications

Main Voltage
Operating Temperature
Storage Temperature
Operating Humidity
Dimensions:
Weight
Power Consumption
Thermal Dissipation

Laser precautions

CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
Do not point laser or allow laser light to be directed or reflected toward other people or
reflective objects.
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the included
instructions are not followed.
Caution – use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
Laser Parameters:
Wavelength 450nm - 460nm
Mode of operation Pulsed, due to frame rate
Pulse duration 0.93ms
Pulse repetition rate 240Hz
Maximum laser energy 0.48mJ
Total internal power 240Wmax
Rev A November 2018
110-240 VAC 50/60Hz
0°C to 40°C (32 F to 104 F)
40°C to 45°C (104 F to 113 F) with reduced light output
-20°C to 60°C (-4 F to 140 F)
10% to 90% non-condensing
W 748 mm (29.4 in), H 248 mm (9.8 in), D 530 mm (20.9 in)
54 kg (119 lb) without lens
at 110 VAC: typical 1250 W in Normal mode
typical 1000 W in Eco mode
at 240 VAC: typical 1900 W in Normal mode
typical 1200 W in Eco mode
at 110 VAC: typical 4334 BTU/hr in Normal mode
typical 3412 BTU/hr in Eco mode
at 240 VAC: typical 4146 BTU/hr in Normal mode
typical 3276 BTU/hr in Eco mode
Important Information
Page 5
