EPSON AcuLaser CX11/CX11F

NOISE

Sound Pressure
Table 1-3. Sound Pressure
Model During printing
Base model 54dB
FAX model 57dB
NOTE 1: Conforms to ISO-7779 concerning measurement and calculation methods
2: Figures are actual measurement values (when copying in monochrome)
Sound Power
Table 1-4. Sound Power
Model During printing
Base model 6.6B
FAX model 6.8B
NOTE 1: Conforms to ISO-7779 concerning measurement and calculation methods
2: Figures are actual measurement values (when copying in monochrome)
Standby mode Sleep mode
Background noise Background noise
Background noise Background noise
Standby mode Sleep mode
Background noise Background noise
Background noise Background noise

1.2.1.2 Electrical Characteristics

POWER SUPPLY VOLTAGE

Power supply operating voltage/frequency
AC 220V/240V ± 10% : 50Hz/60Hz ± 3Hz
Power supply for the controller (TBD)
DC 5.0V ± 5% : 1A or lower
DC 3.3V ± 5% : AVG
: MAX
DC 24.0V ± 10% : MAX

POWER CONSUMPTION

The maximum rated current and power consumption are measured with all engine
options and controller options installed.
Base model/Fax model
Maximum Rated Current
Power Max.
Consumption
Continuous copy using ADF
(average)*
Standby (average) (heater ON, scanner lamp OFF)
Low power consumption (average) (heater OFF)
Power switch OFF
Note *: As for the base model, the values are measured when performing printing.
Scanner consumption current
Table 1-5. Scanner Consumption Current
Output voltage Without ADF
24V
12V
Revision B
3.0 A
4.0 A or lower
1.0 A
120V
7.5A
740W
Color 189W
Monochrome 287W
49W
16W
0W
With ADF
0.55A 0.83A
0.07A 0.07A
240V
4.0A
790W
191W
294W
51W
18W
0W
21
