Modifying Table Views

Much of the information displayed in Ridgeline is in tabular format. You can sort the rows in a table,
modify the table column size, move columns around in a table, and remove columns from a table.

Sorting Table Rows

You can sort the rows of a columnar display according to the contents of any individual column. To
sort the rows, click on the column heading you want to use as the sort criteria. Click once to sort in
ascending order; click a second time to reverse the sort order.
The column that is currently being used as the sort criteria is indicated with a small triangle in the
column heading cell. The direction of the triangle (facing up or facing down) indicates whether the sort
is ascending or descending.

Resizing Table Columns

You can resize the widths of each column. To do this, follow these steps:
1 Place the cursor over the line separating the column you want to resize from the column to its right.
2 Click and hold the left mouse button to "grab" the column separator.
3 Drag the separator until the column is are the desired width.

Moving Table Columns

To move a column in a table, click and hold the left mouse button to "grab" the column heading, then
drag the column to where you want it to be in the table.

Removing Columns From a Table

To remove one or more columns from a table, follow these steps:
1 Click on the icon in the upper right corner of the table you want to modify. A window such as
the following appears:
Figure 6: Selecting Columns to Display in a Table
2 Uncheck the columns you want to remove from the table and click OK. Columns that cannot be
removed from the table are greyed out.
