3 Lines/Trunks
Identifying Line/Trunk Jacks
Table 3–1. Line/Trunk Jack Types
Line/Trunk
Module Type Jack Type
400 Loop-start (LS) 4
800
408
400 GS/LS Ground-start/
800 GS/LS loop-start
408 GS/LS (GS/LS)
408 GS/LS-MLX
800 GS/LS-ID
800 DID DID
(Hybrid/PBX)
800 NI-BRI NI-1 BRI
400EM Tie
100D DS1
NOTES:
1. You cannot mix T1 and Primary Rate Interface (PRI) service on the same
100D module. Any of the following AT&T Switched Network (ASN)
Services can be provided through a T1 or PRI facility: Megacom WATS,
Megacom 800, Software Defined Network (SDN), and MultiQuest . PRI
also supports Call-by-Call Service Selection and some ACCUNET
switched digital services. T1 supports Shared Access for Switched
Services (SASS) and ACCUNET Switched Digital Service (or other
circuit-switched data service) at 56-kbps. Both support Dialed Number
Identification Service (DNIS).
2. The MERLIN LEGEND Communications System supports Centrex
service with loop-start lines only. The system does not support a timed
switchhook flash with ground-start trunks or ground-start emulation on
DS1 facilities in any mode of operation (Hybrid/PBX, Key, or Behind
Switch).
Number of
Jacks Used to Connect
Line/Trunk Types: Basic,
8 Special Purpose (FX, WATS)
4
Auxiliary Equipment: Music On Hold,
Loudspeaker paging system,
Maintenance Alarm, MERLIN
Identifier
4 Line/Trunk Types: Basic,
8 Special Purpose (FX, WATS)
4
4 Auxiliary Equipment: Music On Hold,
8 Loudspeaker paging system,
Maintenance Alarm, MERLIN
Identifier
8 DID
8 (16 channels) NI-1 BRI
4 Tie
1 (24 channels) T1
T1 Switched 56 Data
PRI
