3 Lines/Trunks
Selecting Line/Trunk Options
Outmode Signaling
The system is factory-set to generate touch-tone signals when users dial outside
calls. Identify any rotary-dial trunks that are connected to the system so that
rotary-dial signals can be used for these trunks.
NOTE: NOTE: NOTE:
Touch-tone, single-line telephone users cannot make calls using rotary-dial
trunks unless their phones allow them to switch between touch tones and
rotary dial pulses. Check with the local or long-distance telephone company
to determine which, if any, trunks connected to the system are rotary-dial
trunks.
Planning Form Instructions
In the Outmode Signaling column on Form 2c, do one of the following:
For touch-tone trunks (factory setting), put a check in the TT column.
For rotary-dial trunks, put a check in the R column.
Toll Type Prefix Required
Toll Type allows the system to classify calls as either local or toll, based on the
number dialed by the user. Normally, people have to dial a toll-call prefix
(1 or 0) before dialing the area code and telephone number for a toll call. In some
areas this is not necessary; dialing a prefix depends on local telephone company
requirements and the type of line/trunk used.
Find out from the local telephone company which trunks require a toll-call prefix.
This information is used by the system when a toll call is placed by an extension
on ground-start or loop-start trunks.
For reliable toll restriction, telephone company trunks must require 1 or 0 for toll
calls. Also, the Toll Type feature does not apply to tie trunks.
Planning Form Instructions
On Form 2c, in the Toll Type Prefix Required for LD column, check Yes next to any
trunks on which people need to dial a prefix when placing toll calls.
