3 Lines/Trunks

Assigning Lines/Trunks

Assigning Lines/Trunks
This section contains instructions for assigning lines/trunks to telephones and
Direct-Line Consoles.
NOTE: NOTE: NOTE:
To assign lines/trunks to data-only stations, follow the instructions in
Chapter 5, "Data Communications."
Forms Needed
Form 2a, System Numbering: Extension Jacks
Form 2b, System Numbering: Digital Adjuncts
Use the following forms as appropriate for telephones and consoles in the
system. Make one copy of the appropriate form for each extension.
Planning Form Instructions
1. On page 1 of Forms 4b, 4d, 5a, and 5b, transfer the following user
information from Form 2a, System Numbering: Extension Jacks to each
copy of each of these telephone forms:
a.
b.
c.
2. For any
of Form 2a, indicate the type of extension jack pairs under the Extension
Jack Pair heading on Forms 4b and 5a, by doing one of the following:
— Form 4b, Analog Multiline Telephone
— Form 4d, MLX Telephone
— Form 4e, MFM Adjunct: MLX Telephone
— Form 4f, Tip/Ring Equipment
— Form 5a, Direct-Line Console (DLC): Analog
— Form 5b, Direct-Line Console (DLC): Digital
— Form 5c, MFM Adjunct: DLC
Write the logical ID in the Logical ID space.
Write the extension number in the Extension No. space.
Write the name of the person or the location of the equipment in the
Person or Location space.
voice/voice or voice/data
Check the Voice Announce to Busy (voice/voice) box, and enter the
logical ID and extension number under the Even-numbered jack
heading.
Check the Simultaneous Voice and Data (voice/data) box, and enter
the logical ID and extension number under the Even-numbered jack
heading.
3
entries in the Person or Location column
Issue 1
August 1998
Page 3-50
