F Unit Load Calculation
Unit Load Worksheet
5. Calculate the estimated unit loads.
Module
008
008 MLX
008 OPT
012 T/R
016 T/R
100D
400 LS
400 EM
400 GS/LS/TTR
408
408 GS/LS
408 GS/LS-MLX
800
800 GS/LS
800 DID
800 GS/LS-ID
MERLIN LEGEND Mail
Total Estimated Unit Load
If the total is less than 75 (for the 391C1 or 391A3 power supplies) or 54 (for
the 391A1 or 391A2 power supplies), no further calculation is required.
If the total is 75 (391C1 or 391A3 power supplies) or 54 (391A1 or 391A2
power supplies) or more, continue to Step 6.
6. Calculate the actual carrier unit load using the table on the next page.
If the total actual unit load is less than or equal to 75 (391C1 or 391A3
power supplies) or less than or equal to 54 (391A1 or 391A2 power
supplies), no further calculation is required.
If the total actual unit load is more than 75 (391C1 or 391A3 power supplies)
or more than 54 (391A1 or 391A2 power supplies), continue to Step 7.
Unit
Qty x Load
12.0
13.25
8.0
8.4
12.8
0.0
0.0
8.0
0.0
12.0
12.0
13.5
0.0
0.0
8.0
8.0
0.0
Issue 1
August 1998
Page F-4
= Total
