2 Control Unit Configuration
Numbering the System
Planning Form Instructions
On Form 2a, mark the extension jack assignments on the 012 T/R, 016 T/R,
MERLIN LEGEND Mail, and 008 OPT modules:
1. In the Jack Type column, make sure B is checked next to the logical ID for
each basic telephone jack.
2. In the Person, Location, or Function column, identify each T/R device by
the users name or location and by type, such as single-line telephone, fax,
modem, or Delay Announcement Device.
3. If the system includes optional applications, indicate the application on the
appropriate line in the Appl column:
4. If the system has Messaging 2000 or AUDIX Voice Power, also write
in the Appl column for any logical IDs that are being used for fax ports.
5. If the system is to be part of a Centralized Voice Messaging system
(Release 6.1 and later systems only), check Yes under the Centralized
Voice Messaging heading. Also check Yes on page 4 of the MERLIN
LEGEND R6 Design Implementation Guide form located in Appendix I. If
not part of a Centralized Voice Messaging system, check No on both forms.
6. For each 016 T/R module, if applicable, indicate the Ringing Frequency for
that module. Enter
the 016 T/R module. When configuring a system in the United States or
Canada, generally the 20-Hz setting is applicable. The factory setting is
20-Hz.
Proceed to the next section, "Labels".
To indicate MERLIN LEGEND Mail, write
To indicate Messaging 2000, write
To indicate Intuity AUDIX, write
To indicate Enhanced Service Center, write
To indicate CONVERSANT, write
To indicate MERLIN MAIL voice messaging system, write
To indicate Lucent Technologies Attendant, write
To indicate AUDIX Voice Power IS II or IS III, write
To indicate Integrated Voice Power Automated Attendant-IS II, write
IVP-AA .
To indicate no applications, write
NOTE:
For more information on Centralized Voice Messaging, see the
Network Reference .
20-Hz or
ML Mail
M2000
Intuity .
CONV .
None .
25-Hz in the Ring Freq. column for all ports on
