If Talk Time is enabled, an asterisk (*) indicates an abandoned call. This occurs
when the calling party disconnects a call being directed to an Auto Login or Auto
Logout calling group before a member answers, even if the call was answered
elsewhere in the system (unless the call is on a loop-start facility that does not
have reliable disconnect supervision).
NOTES:
1. For accurate reports, the system date must be set to the current date
when the system is installed. Be sure you checked the Yes box on Form 1
under Set System Date.
2. For systems where the majority of lines are PRI facilities, the SMDR Call
Length should be programmed for one second.
3. When SMDR is used with the MERLIN LEGEND Reporter, the settings
for Call Length and Calls Reported have no effect on SMDR reporting for
calling group calls.
Planning Form Instructions
In the SMDR Options section of Form 8a:
1. Under the Call Format heading, do one of the following:
2. Under the Call Length heading, do one of the following:
3. Under the Calls Reported (non-UDP) heading, do one of the following:
Under the Calls Reported (UDP) heading, do one of the following:
4.
5. Under Talk Time heading, do one of the following:
To keep the factory-set format, check the Basic box.
To change the report format, check the ISDN box.
To keep the factory-set call length, check the 40 seconds box.
To change the factory-set call length, check the second box and
write the number of seconds (0–255) in the space provided.
To keep the factory setting, check the Incoming and outgoing box.
To change the factory setting, check the Outgoing only box.
To keep the factory setting, check the Incoming and outgoing box.
To change the factory setting, check the None box.
To keep factory setting, check the Disable box.
To change the factory setting, check the Enable box.
