Lucent Technologies MERLIN LEGEND Release 6.1 System Planning Manual page 350

MERLIN LEGEND
Form 3b
(Continued)
Module 3 Slot No. __________
Type of Service
Switch Type
T1 *
†‡
PRI
T1 Trunks
Channel
Trunk Type
Number(s)
Ground-Start
Loop-Start
Tie
Unequipped
All Ground-
Start
All Loop-Start
All Tie
All Unequipped
DID
All DID
S56 Data
All S56 Data
NOTE: Do not configure 100D modules to do trunk-to-trunk transfers between DS1 and LS lines/trunks.
Factory Setting
* The factory setting of T1 is not automatically selected if you enter nothing; it must be entered.
† PRI must be selected as the Type of DS1 connectivity before PRI options are entered.
‡ AT&T Toll and 5ESS local PRI service for Release 2.0 and later requires service provider switching equipment to be either
4ESS Generic 13 through Generic 16, 5ESS Generic 6, or a 5ESS serving the FTS2000 network. PRI service on Release 1.0
or 1.1 requires a DS1 facility from a 4ESS Generic 13 through Generic 16 or 4ESS Generic 16 switch.
Form 3b-2
® Communications System Release 6.1
(PRI Service Only)
‡
4ESS * DEX600E
‡
5ESS Legend-PBX
DMS-100 Legend-NTWK
DMS-250
For Tie/All Tie
Tie-PBX Toll
Frame Format
D4 Compatible
Extended Superframe (ESF)
Suppression (Line Code)
AMI-ZCS
B8ZS
S56
Signaling Mode
Robbed-Bit Signaling
(RBS)
Common-Channel
Signaling (CCS)
Line Compensation
__________ Cable Feet
1 (-.6 dB)
2 (-1.2 dB)
3 (-1.8 dB)
4 (-2.4 dB)
5 (-3.0 dB)
Clock Synchronization
Priority
Primary
Secondary
Tertiary
None
Source
Loop
Local
Activation
Active
Not Active
Channel Service Unit
Foreign Exchange
Special Access
