Lucent Technologies MERLIN LEGEND Release 6.1 System Planning Manual page 94

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
2 Control Unit Configuration
Numbering the System
Planning Form Instructions
Use Figure 2–2
1. On Form 2a and 2b, if this switch is part of a private network, check Yes
under the Networked Switch heading. If the switch is not part of a private
network, check No.
2. Identify the 2-digit, 3-digit, or Set Up Space numbering system you will be
using under the Factory Set column on Form 2b, by circling the name of the
appropriate numbering system.
3. Do one of the following:
Proceed to the next section, "Updating Planning Information".
Updating Planning Information
On the floor plan, add the extension number beneath the symbol for each
telephone and adjunct. If you are using a system programming console, go to
Form 1, System Planning, in the System Operating Conditions section and add
the new extension number of the console in the space next to Ext. No.
NOTE: NOTE: NOTE:
The remaining columns on Form 2a (Eqpt., Label, Old Ext. No., and
Wire No.) are completed by the technician during installation.
To complete the forms for lines/trunks, proceed to Chapter 3, "Lines/Trunks".
through Figure 2–4
NOTE:
For more information, see the Network Reference .
If you do not need to renumber any of the factory-set extension
numbers:
a. Check the 2-Digit, 3-Digit, or Set Up Space box under the
Renumber System heading on Form 2a to indicate the
numbering plan you're using.
b. Skip to the next section, Updating Planning Information.
If you want to renumber only a few of the extensions and there are
enough numbers available for 2- and 3-digit numbering plans:
a. Check the 2-Digit, the 3-Digit, or the Set Up Space box to
indicate the numbering plan you're using. Be sure to check
Selected Extension Numbers under the Renumber System
heading on Form 2a , page 1 .
b. Write the new extension number(s) in the Renumber to
columns on Form 2a and Form 2b.
as you record extension number information:
2
Issue 1
August 1998
Page 2-36
2
