Lucent Technologies MERLIN LEGEND Release 6.1 System Planning Manual page 202

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
4 Features
System Features
Automatic Callback
This section contains instructions for setting the number of rings the system
should use to alert a caller about a callback attempt. After the specified number of
rings, the system abandons the callback attempt.
Planning Form Instructions
Under the Automatic Callback Interval heading on Form 8a, do one of the
following:
To keep the factory-set interval, check the 3 rings box.
To change the factory-set interval, check the second box and write the
number of rings (1–6) in the space provided.
Extension Status
This section contains instructions to set Extension Status to allow an operator, a
calling group supervisor, or a Call Management System (CMS) supervisor to
determine the status of a telephone at a glance. The lights next to the buttons on
a DSS or next to Auto Dial buttons programmed with extension numbers indicate
the status of the telephone.
In Hotel mode, Extension Status (ES) affects a station's calling restrictions. Only
an ES operator can use a DSS to turn off states ES1 or ES2 to remove calling
restrictions. In CMS mode, Extension Status does not affect calling restrictions.
NOTE: NOTE: NOTE:
In Hotel mode, an ES-restricted station can call a remote private network
extension.
Decide on the configuration and assign operator positions to monitor extension
status.
Planning Form Instructions
Under the Extension Status heading on Form 8a:
1. Check the Assign to operator positions box and write the extension number
for each operator position in the space provided. See the appropriate copy
of Form 5a or 5b.
2. Do one of the following:
To keep the factory-set configuration, check the Group Calling/CMS
box.
To change the configuration, check the Hotel box.
4
4
Issue 1
August 1998
Page 4-44
