MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
2
Control Unit Configuration
Numbering the System
7.
To indicate the primary DLC operator position:
Proceed to the next section, "Jacks for Additional Operator Positions".
Jacks for Additional Operator Positions
Use these instructions only if the system has more than one operator position.
Otherwise, skip to the next section, "Extension Jack Pairs for Analog Telephones".
The maximum number of operator positions is shown in
Table 2–7.
Position
QCC
DLC
DLC
Any combination of operator positions can be assigned as long as no more than
four are QCCs and the total combined number is no more than eight. For
example, a system can have a combination that consists of four QCCs, two MLX
DLCs, and two analog DLCs. The Call Management System (CMS) equipment
connects to analog extension jacks assigned as DLC positions. You must assign
two DLC positions for each CMS (maximum of two) connected to the system on
analog multiline modules.
Planning Form Instructions
NOTE:
NOTE:
NOTE:
For each CMS connected to the system, you must assign two analog DLC
positions. These two DLCs do not need to have the factory setting
extension numbers but do need to be on the same module.
Locate the first extension jack showing a jack type of D (digital) or A
(analog) and write
DLC
Write the name or location of the primary DLC operator in the
Person, Location, or Function column.
On Form 1 (page 2), write the extension of the DLC under System
Consoles.

Maximum Number of Operator Positions

Telephone
MLX-20L
MLX-20L
MLX-28D
Analog multiline
telephones
beside the preprinted logical ID number.
2
Table
Maximum
4
8
8
Issue 1
August 1998
Page 2-22
2–7.
2
