Assigning Extension Jacks

Assigning Extension Jacks
Following some guidelines about digital extension jacks, this section contains
procedures to plan extension jack connections for the following:
Modem data-only stations
ISDN terminal adapter data-only stations
Local host computer data stations
LAN workstations
Video systems (personal or group)
For each type of data station, planning how the data equipment connects to
extension jacks on the control unit involves the following tasks:
1. Review Form 2a, on which you entered codes (A for analog, D for digital,
and B for basic telephone) and find the telephone type and the user,
location, or function for each data station to be connected.
extension jack types, the corresponding module types, and the equipment
that can be connected.
2. Add the extension jack assignments to Form 2a.
Table 5–4.

Extension Jack Types

Jack Type Module Type Connects
Analog 008
408
408 GS/LS
Digital 008 MLX
408 GS/LS-MLX
Basic 012
016
008 OPT
Before you assign extension jacks for ISDN terminal adapter data stations, review
the guidelines in the next section, "Guidelines for Digital Extension Jacks."
Analog multiline telephones (including analog voice-and-data stations
with a modem connected through a GPA)
MLX telephones (including MLX voice-modem data stations)
MLX telephones (including MLX voice and ISDN terminal adapter
stations)
ISDN terminal adapter data terminals (such as PCs)
Video systems (personal or group)
T/R equipment:
Single-line telephones
Adjuncts, such as fax or answering machines
Modem data-only stations
Tip/ring equipment in another building or offsite
5
Table 5–4
Issue 1
August 1998
Page 5-21
