3 Lines/Trunks
Assigning Telephone Buttons
5 BUTTON
Figure 3–5.
Although equipment such as single-line telephones, analog modems, and fax
machines do not have buttons, the system treats these as multiline telephones
with 34 buttons. In both Key and Behind Switch modes, the system assigns no
outside lines to this type of equipment. The system assigns two ICOM Ring
buttons to equipment connected to an 012 T/R, 016 T/R, or 008 OPT module. The
system assigns an ICOM Ring and an ICOM Voice button to every adjunct
connected through an MFM. You MUST remove the ICOM Voice button.
22 BUTTON
10 BUTTON
5
4
3
Icom
2
Voice
Icom
1
Ring
Factory-Set Assignment, Analog Multiline Telephones
(Key and Behind Switch Modes)
34 BUTTON
10 11
9 12
13
8
14
7
6 15
16
17
18
19
20
21
22
