MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
4
Features
Telephone and Extension Features
Planning Form Instructions
1.
On page 1 of Form 4a and/or Form 4c, write the extension number of the
Master Extension and the extensions to which this template will be copied.
2.
Complete the Button Diagram on page 2 of Form 4a and/or Form 4c,
assigning features to the buttons.
3.
On the individual telephone forms (Forms 4b, 4d, 4e, 5a, 5b, and 5c) do the
following:
a.
b.
Cover Ring Delay
Beginning with Release 4.1, the following ring delay options can be programmed
for extensions:
The Group Coverage Ring Delay is programmed on individual sender
extensions and replaces the Coverage Delay Interval programmed on a
systemwide basis in previous releases.
When used in conjunction with Secondary Cover buttons, consider the
following when setting the value:
The Primary Cover Ring Delay and Secondary Cover Ring Delay are
programmed on individual sender extensions and replace the Delay Ring
Interval programmed on a systemwide basis.
Forms Needed
Form 4b, Analog Multiline Telephone
Form 4d, MLX Telephone
Form 4e, MFM Adjunct: MLX Telephone
Form 4f, Tip/Ring Equipment
Form 5a, Direct-Line Console (DLC): Analog
Form 5b, Direct-Line Console (DLC): Digital
Form 5c, MFM Adjunct: DLC
Form 7c, Group Coverage
By the extension information at the top of each page, check Copied
from Master Extension No. and write the extension number of the
Master Extension.
Under every form's Button Diagram heading, check the See Master
Extension box.
— When secondary cover buttons are programmed for a sender, set
the value such that when the Group Coverage Ring Delay is added
to the Primary Cover Ring Delay, the result is greater than the
Secondary Ring Delay plus two rings (the fixed Secondary Cover
Delay Interval).
4
Issue 1
August 1998
Page 4-14
4
4
