Lucent Technologies MERLIN LEGEND Release 6.1 System Planning Manual page 242

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
5 Data Communications
About Data and Video Communications
MLX Voice and Modem Data
This type of analog data station includes an MLX telephone in addition to the DTE
and modem (see
through the T/R interface of the Multi-Function Module (MFM), which is installed in
the MLX telephone. The telephone connects to the control unit through an MLX
extension jack. The communication capabilities of the MLX telephone and data
station can be used simultaneously.
Optical
Scanner
Fax
Credit Card
Verification
PC Terminal
Host
Computer
Figure 5–3. MLX Voice and Modem Data
Figure 5–3). The modem connects to the MLX telephone
Data Station
DTE
Digital
Signal
T/R
MLX Telephone/
with Multi-Function
Module (MFM)
5
MERLIN
DCE LEGEND
Control
Analog
Signal
Modem
MLX-20L
Home More
Menu Inspct
Digital
Message
v Volume v ABC DEF
1 2 3
Feature Transfer GHI JKL MNO
4 5 6
HFAI Conf
PQRS TUV WXYZ
7 8 9
Mute Drop
* OPER #
Speaker Hold 0 Signal
August 1998
Page 5-10
Unit
Analog or Tip/Ring
Extension Jack
MLX
Extension Jack
Issue 1
