MERLIN LEGEND Communications System Release 6.1
T1/PRI Planner
Clock
Connection 1
CO
PBX
PRI**
T1 Emulated Trunks
Tie
LS
GS
DID
S56 Data
Services
Key:
Digital Transmission
Facility
Primary Synchronization
Source
P
Secondary Synchronization
Source
S
Tertiary Synchronization
Source
4
(Continued)
DS1 Planning Map
CONTROL UNIT
100D 100D
MODULE 1 MODULE 2
SLOT:____ SLOT:____
Approximate Approximate
Distance_____ Distance_____
CSU
Acculink 3150
Other*
None
Connection 2
CO
PBX
PRI**
T1 Emulated Trunks
Tie
LS
GS
DID
S56 Data
Services
T
100D
MODULE 3
SLOT:____
Approximate
Distance_____
CSU CSU
Acculink 3150 Acculink 3150
Other* Other*
None None
* Other model numbers
** The switching equipment
of the service provider
must be 4ESS Generic 13 or later
or 5ESS G6 or later.
Connection 3
CO
PBX
PRI**
T1 Emulated Trunks
Tie
LS
GS
DID
S56 Data
Services
