MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
F
Unit Load Calculation
Unit Load Worksheet
Unit Load Worksheet
1.
Number of modules in carrier (excluding power supply
and processor):
If fewer than 5, no further calculation is required.
If 5 or 6, continue to Step 2.
2.
Key or Behind Switch mode only:
Indicate the configuration of lines; then go to Step 5.
3.
Hybrid/PBX mode only:
Do all modules in the carrier have MLX and/or
analog multiline telephone jacks?
If no, no further calculation is required.
If yes, continue to Step 4.
4.
Hybrid/PBX mode only:
Calculate the total number of MLX and analog
multiline telephones.
Number of MLX-20L telephones connected to
modules in the carrier:
Number of MLX-28D telephones connected to
modules in the carrier:
Number of 34-button analog multiline telephones
connected to modules in the carrier:
Total of MLX-20L, MLX-28D, and 34-button analog
telephones
If the total is less than 45, no further calculation is
required.
If the total is 45 or more, continue to Step 5.
F
__________________
Key
Modified
Yes
No
__________________
__________________
__________________
__________________
Issue 1
August 1998
Page F-3
