MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
2 Control Unit Configuration
Numbering the System
Table 2–1.

Application Ports

Ext.
Module Jack Type
008 Analog
408
408 GS/LS
008 MLX Digital
408 GS/LS-MLX
012 Basic
016 Telephone
008 OPT
MERLIN Analog
LEGEND Mail
* No longer orderable.
†
When using the 008 MLX or 408 GS/LS-MLX module for data or video, you must use Version 28 of
the module.
** ISDN terminal adapters include such devices as: Ascend Pipeline 25PX or 50.
‡ The system uses 12 logical IDs for an 008 OPT module, even though only eight will have equipment
attached to them. Do not use an 008 OPT module for applications (such as MERLIN LEGEND Mail,
Messaging 2000, or Intuity AUDIX VS). Be sure to leave the extra four ports blank on Form 2a.
§
The MERLIN LEGEND Mail module has 7 dedicated internal ports, but assigns 12 total extensions.
No.
of Jacks Used to Connect
8 Analog multiline telephones
8 TransTalk Wireless telephones
8 Call Management System (CMS)*
8 MLX telephones with or without PassageWay
Direct Connect Solution
8 CTI link
Desktop video endpoints
Group Video endpoints
Digital data devices, such as an ISDN terminal
†
adapter
12 Tip/ring equipment, such as:
16 Single-line telephones
Delay Announcement Devices
Adjuncts, such as analog modems or fax
machines or MERLIN
Optional applications:
Enhanced Service Center
Messaging 2000
Intuity™ AUDIX VS
MERLIN MAIL
®
AUDIX Voice Power (IS II or III)*
‡
8 Tip/ring equipment in another building or off
premises
Off-Premises Range Extender
§
0 Provides MERLIN LEGEND Mail
†
and/or
†
**
®
Identifier
®
Voice Messaging System*
Issue 1
August 1998
Page 2-15
