4 Features
System Features
To complete the Call Type column, enter one of the following:
6.
7. If you have worked on only one of your planned non-default tables,
complete all copies of Form 3f. Repeat Steps 1 through 6 for each table
(Tables 1 through 16) that you need.
8. If you have not completed the factory-set tables, do so now:
a.
b.
!
c.
For voice only calls, write
For data only calls, write
For both voice and data calls, write
NOTE:
Pools should be labeled as Voice unless they can support digital
data. Both can be used for BRI, PRI, and private network PRI pools.
Data can be used for T1 Switched 56 pools, and to reserve lines for
data in BRI, PRI, and private network PRI pools.
For Tables 17 (Default Toll) and 18 (Default Local), repeat Steps 1
through 6 to complete the subpattern and pool routing sections.
For the Dial 0 table (Table 19) complete the Pool routing, Facility
Restriction Level (FRL) and Other Digits entries following Steps 2
through 4. If the switch is part of a private network, and the private
network needs to use the Dial 0 table, see the Network Reference
for information.
WARNING:
In the next step, assigning a restrictive FRL could impair the ability to
dial 911.
If users need to dial an access code to call the special numbers 411,
611, 811, and 911, record that code on the Special Number Table
20), under the Other Digits heading. Assign the FRL as shown in
Step 3. If the switch is part of a private network, and the private
network needs to use the Special Numbers table, see the Network
Reference for information.
V
.
D .
Both .
