3 Lines/Trunks
Identifying Line/Trunk Jacks
3. If the option is programmed on a 2-way trunk, the system will not seize a
trunk from the pool for an outgoing call when that trunk is receiving an
incoming call.
4. Use the LS-ID Delay option if the adjunct or application does not allow
line buttons to be set for Delay Ring.
5. If the option is programmed on a trunk administered as a DGC trunk, the
system will not dispense the call to either the DGC queue or to any calling
group member until either the LS-ID Delay timer expires or the system
software is informed that ICLID information is unavailable.
Planning Form Instructions
Refer to the completed Control Unit Diagram on Form 1 to mark line/trunk jack
types on Form 2c:
1. For each module with line/trunk jacks noted in the Control Unit Diagram
(beginning with Slot 01), write in the type of module and its slot number in
the Module Type and Slot No. column of Form 2c; after the appropriate
Log. ID number, draw a line to indicate the logical IDs (and therefore, the
line/trunk jacks) that correspond to that module.
If the system has 100D (DS1) modules, keep in mind that even though the
module has only one physical jack, the 100D module supports up to 24
endpoints. Therefore, 24 logical IDs and associated line/trunk numbers are
assigned to each module.
Likewise, the 800 NI-BRI module supports up to 16 endpoints or
extensions, therefore 16 logical IDs and associated line/trunk numbers are
assigned to each 800 NI-BRI module even thought the module has only
eight physical jacks.
2. In the Jack Type column of Form 2c, for all modules except 100D modules,
write the jack type for each logical ID. Use the codes shown in
Issue 1
February 1998
Page 3-5
3
Table 3-2.
