MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
2 Control Unit Configuration
Numbering the System
Table 2-6.
Application
MERLIN MAIL
Lucent Technologies
Attendant
AUDIX Voice Power
MERLIN LEGEND Mail
Intuity AUDIX
NOTES:
1. Older versions of the 012 module, (apparatus codes 517C13–517F13) if
one or more applications are used, only four tip/ring (T/R) devices may be
assigned to the module where the application is assigned, regardless of
how many jacks are open.
2. The applications discussed here do not work properly with 012 modules
manufactured for older MERLIN II systems. These applications must be
connected to 012 modules with the code 517C13 or 517D13 (or higher)
labeled on the top of the module. Modules with the code 517A13 or
517B13 can be used to connect single-line telephones only. They do not
provide the disconnect signal required by answering machines and
applications. Do not use the 008 OPT module for applications such as
AUDIX Voice Power, MERLIN MAIL, or Lucent Technologies Attendant.

Application Ports

Ports
2
4
1
2
3
4
2
4
6
8
2
4
6
4
6
8
10
12
TTRs Telephones
1 5 + 1 for the modem
2 3 + 1 for the modem
1 6 + 1 for programming
1 5 + 1 for programming
2 4 + 1 for programming
2 3 + 1 for programming
1 6
2 4
3 2
4 0
1
1
2
2
3
4
5
6
Issue 1
February 1998
Page 2-29
