2 Control Unit Configuration
Numbering the System
Jacks for Tip/Ring Equipment and Applications
Use these instructions only if the system includes 012, 016, or 008 OPT modules.
Otherwise, skip to the next section, Labels.
Assign the basic telephone jacks on the 012, 016, or 008 OPT modules to any
tip/ring equipment such as single-line telephones, fax machines, modems, or
DGC Delay Announcement Units. The hardware design of the 008 OPT module
includes an interface for off-premises telephones, which includes increased gain
levels and protection.
If assigning basic telephone jacks on an 016 module, the Ringing Frequency may
be set to either 20-Hz (Type A) or 25-Hz (Type E). The Ringing Frequency is
administrable on each 016 module and affects all ports on that 016 module.
Several optional applications, if used with the system, require basic jacks on a
012 or 016 module: MERLIN MAIL VMS, Lucent Technologies Attendant, AUDIX
Voice Power-Integrated Solution II (IS II) or III (IS III), MERLIN LEGEND Mail,
Intuity AUDIX, and Integrated Voice Power Automated Attendant-IS II or IS III. Do
not use the 008 OPT module for these applications.
NOTE: NOTE: NOTE:
If the system has AUDIX Voice Power, the Integrated Administration feature
provides a single interface through Integrated Solution III (IS III) for
programming entries common to the system and to the AUDIX Voice Power
system. These common entries are noted on the planning forms, and
instructions for planning the system in conjunction with planning for the
AUDIX Voice Power system are included in the procedures throughout this
book. For more information about this and other applications, see the
Feature Reference .
The system can accept up to eight application ports (extension jacks for
applications) using the 012 module [517J13]. All 16 ports on the 016 module
(517C34) may be used for applications.
Table 2-6 shows, by application, the number of ports used, the number of TTRs
required, and the number of additional single-line telephones that can be added to
the modules. Use this table as a guideline.
