D T1/PRI Planner
The NTSC group's preauthorization review is based, in part, on information you
provide to them. Specifically, you must send them the following:
A copy of the planner
A completed "Non-Complex Configuration" sheet (pages 5 through 10 of
the Planner) for each 100D module you plan to install
Complete one Non-Complex Configuration page (pages 5 through 10) for each
100D module. Label the top right corner of the copies "Page 1 of _ " (1, 2, or 3).
On each page:
1. Write the module number (1, 2, or 3). Indicate the total number of 100D
modules (maximum of 3 for each system).
2. Fill in the control unit slot number (refer to page 1 of Form 3b).
3. In the Services section:
a.
b.
4. If the type of service is PRI, complete the PRI Identification Service section
by doing one of the following:
Check the box next to each emulated trunk or service that will be
connected. Check only those services allowed on the type of service
(T1, AT&T Toll, MCI Toll, or DMS Local) selected for the module.
Circle the channel(s) to which each emulated trunk or service will be
assigned.
NOTE:
No channel should show more than one trunk or service, and the
24th channel cannot be used if the signaling type is common
channel.
If you are not planning to use the number identification service,
check the No box and proceed to Step 5.
If you are planning to use the identification services, check the Yes
box and check the service planned:
— For incoming calls, check one of the following boxes: ANI,
SID, or Both. If both automatic and extension identification
service are planned, indicate the order in which the informa-
tion should be displayed (ANI then SID or SID then ANI).
— For outgoing calls, check either ANI, SID/ANI Privacy,
SID — Extension Based, or SID — Line Based to indicate
the service planned.
NOTE:
The availability of the caller identification information may be limited
by local-serving (caller's) jurisdiction, availability, or central office
equipment.
