3 Lines/Trunks
Selecting Line/Trunk Options
5. To select dial mode:
a.
NOTES:
1. If you have checked the Incoming or two-way column for a tie-trunk's
direction and Immediate for its incoming signaling type, you cannot use
the Touch-Tone setting for Inmode.
2. Touch-Tone outmode can be used with Outtype Immediate trunks, but
Touch-Tone Inmode cannot be used with Intype Immediate Trunks.
b.
6. To indicate whether the system provides a dial tone for people calling in on
a tie trunk, check one of the following for each tie trunk under the Dial Tone
heading:
For Answer Supv. Time, do one of the following:
7.
NOTE:
The 1C option assumes that the two systems are connected together
without any provisioned facility, and without any signaling treatment
equipment. When connecting a MERLIN LEGEND switch to another
MERLIN LEGEND switch, use the 1C signaling type.
If the tie trunks are connected directly to a system that uses type 5
signaling and is located near this system, check 5.
NOTE:
When connecting a MERLIN LEGEND switch to a DEFINITY switch,
use the Type 5 signaling type.
Under the Inmode heading, check either the Touch-Tone column or
Rotary column (factory setting) for each incoming-only and each
two-way tie trunk. Use Touch-Tone for private networks.
Under the Outmode heading, check either the Touch-Tone column
or the Rotary column (factory setting) for each outgoing-only and
each two-way tie trunk.
If the system provides a dial tone, check Remote (factory setting).
Use this setting for private networks.
If the system does not provide a dial tone, check Local.
To keep the factory setting, check the 300 column. Use this setting
for private networks.
To change to a new value, write the new value (20 to 4800 ms) in
the Other column. (Use 20-ms increments.)
