Lucent Technologies MERLIN LEGEND Release 6.0 System Planning Manual page 164

MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
4 Features
Telephone and Extension Features
When a principal user is assigned, calls received on the personal line are also
sent to Individual or Group Coverage receivers unless the personal line button is
set for No Ring. Calls are not sent to coverage if Remote Call Forwarding is
activated.
Planning Form Instructions
1. Under the Remote Call Forwarding heading on Form 6b, do one of the
following:
2. If you want a user to be able to forward the incoming calls on a specific line
or lines to another number, write the extension number in the spaces
provided on Form 6c, Principal User of Personal Line.
3. If Remote Call Forwarding is enabled, do one of the following:
NOTES:
1. If Do Not Disturb (DND) and Forwarding Delay are both active, DND
overrides the Forwarding Delay and the call is forwarded immediately.
2. Due to the timing of when the ringing signal is applied to a Single-line
telephone, and the interval of that ringing signal, Single-line telephones
may appear to have their calls forwarded one ring less than the
administered number.
To prevent users from forwarding calls to outside numbers (factory
setting), check the Not Allowed column and proceed to the next
section, "Fax Message-Waiting Receiver."
To provide Remote Call Forwarding, check the Allowed column,
then proceed to Step 2.
If you wish to disable the Forwarding Delay option, enter
Delay (0–9) column under the Remote Call Forwarding heading on
Form 6b. This causes incoming calls to be forwarded immediately.
If wish to enable the Forwarding Delay option for an extension, enter
the number of times an incoming call should ring at the called
extension (1–9 rings) before the incoming call is forwarded.
Issue 1
February 1998
Page 4-7
4
0 in the
