Lucent Technologies MERLIN LEGEND Release 6.0 System Planning Manual page 171

MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
4 Features
Telephone and Extension Features
Forms Needed
Form 4b, Analog Multiline Telephone
Form 4d, MLX Telephone
Form 4e, MFM Adjunct: MLX Telephone
Form 4f, Tip/Ring Equipment
Form 5a, Direct-Line Console (DLC): Analog
Form 5b, Direct-Line Console (DLC): Digital
Form 5c, MFM Adjunct: DLC
Form 7c, Group Coverage
Planning Form Instructions
1. After assigning Individual Coverage for each receiver telephone, locate the
appropriate form for each sender telephone (Form 4b, 4d, 4f, 5a, or 5b)
2. Under the Primary Cover Ring Delay heading, do one of the following:
3. Under the Secondary Cover Ring Delay heading, do one of the following:
4. After assigning senders to Group Coverage on form 7c, locate the
appropriate form for each sender telephone (Form 4b, 4d, 4f, 5a, or 5b).
5. Under the Group Coverage Ring Delay heading, do one of the following:
To keep the factory-set delay, check the 2 rings box.
To change the factory-set delay, check the second box and write the
number of rings (1 to 6) in the space provided.
To keep the factory-set delay, check the 2 rings box.
To change the factory-set delay, check the second box and write the
number of rings (1 to 6) in the space provided.
To keep the factory-set delay, check the 3 rings box.
To change the factory-set delay, check the second box and write the
number of rings (1 to 9) in the space provided.
Issue 1
February 1998
Page 4-14
