MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
H NI-1 BRI Provisioning
Siemens SSC EWSD Switch Translations
Siemens SSC EWSD Switch
Translations
For the Siemens SSC EWSD switch, Capability Package "S" includes alternate
voice/circuit-switched data on two B-channels. It also supports Calling Number
Identification on data and voice connections. Please note that the assignment of
two Directory Numbers (DNs) is required for this package.
The Siemens SSC EWSD switch allows either voice or data hunting on one DN
using the Series Completion feature. The same provisioning is used for either a
voice or data series completion group.
ISDN Capability Package "S"
The information listed below provides the DN translations that define Capability
Package "S", and the screens and fields that must be populated.
The information provided shows the translations for one DSL and two DNs. For
multiple DSLs/DNs, the CO will duplicate these screens and enter the applicable
DSL and DN values as needed.
ISDN Ordering Code: Capability S
DISPACCESS:EQN=20-0-5-4;
ACCESS DATA
EQN =20-0-5-4,
CLOSS = 0,
BCHEQN =2,
BCEQN = SP
CPDDN = 2156855917-VI
CPVDN2 = 2156855917,
COE = CLASS1,
LINKOPT = DYNNOPAL,
BAPROF = 0;
& AU3 & C56 & C64,
& 2156855917-CMD,
H
H
EXEC'D
MASKNO:04328
MASKNO:00000
Issue 1
February 1998
Page H-30
