4 Features
System Features
System Speed Dial
This section contains instructions for designating systemwide, frequently used
numbers. You can assign and store up to 130 three-digit System Speed Dial
codes. To call one of these numbers, a caller presses the Feature button and
dials a three-digit code.
Assign System Speed Dial codes to telephone numbers that shouldn't be
displayed on telephones, such as access codes. Entries that do not display are
referred to as Marked System Speed Dial entries. You can also assign labels to
the System Speed Dial codes. These labels are listed in the System Directory so
that MLX telephone users can search for them and dial System Speed Dial
numbers with the touch of a button.
Planning Form Instructions
NOTE: NOTE: NOTE:
As a visual aid to distinguish lines during programming, every fourth line on
the form is shaded.
1. Review the analysis of question 9 on the Employee Communication
Survey.
2. On Form 10b, System Speed Dial:
a.
b.
c.
NOTES:
1. Marked System Speed Dial entries (entries that do not display) are not
affected by the Second Dial Tone Timer setting. If the Central Office does
not immediately supply dial tone when a star code is entered and a
Marked System Speed Dial entry uses star codes, then the appropriate
number of pauses (each 1.5 seconds) must be programmed in the entry
following each star code.
2. When a Marked System Speed Dial number (the dialed number is
suppressed from the display) is used to dial a number, calling restrictions
(such as toll or outward restrictions, or Allowed and Disallowed Lists)
assigned to that extension are overridden. When an unmarked System
Speed Dial or a Personal Speed Dial number is used to dial a restricted
number, the call cannot be completed unless the number is on the
Allowed List for that extension.
Write the label (maximum: 11 characters) to be displayed for the
number in the Name column.
Write each telephone number (maximum: 40 digits) in the
Telephone Number column.
To display no number (Marked System Speed Dial entry), check the
No box in the Display column (the factory setting is Yes).
