MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
2 Control Unit Configuration
Numbering the System
c.
2. Using the information from Form 2a, mark the digital extension adjuncts
and video stations on Form 2b, System Numbering: Digital Adjuncts:
a.
b.
c.
d.
e.
3. In the last column, identify the type of equipment connected to the jack or
the ISDN terminal adapter connected to the jack. Also, record the person,
location, or function if desired.
Proceed to the next section, Jacks for Analog Multiline Telephones.
If an extension port will be a CTI link, Write CTI Link in the Person,
Location, or Function column, and Label column, and put a check
mark in the CTI Link column. If this is a CTI link, skip to Step 3. The
CTI Link port must be selected from ports 2, 3, 4, 6, 7, or 8 (the CTI
Link port cannot be the potential operator port or the console
programming port).
Do one of the following:
— If the jack does not have an adjunct connected, write None in
the Adjuncts column and skip to Step 3.
— If an adjunct is connected to the MLX telephone, proceed to
Step b.
If an adjunct is connected to the MLX telephone, enter the type of
adjunct (such as MFM-SAA, MFM-T/R, MFM-DAU, ER1000, 7500B,
ASC 25/50, or ASC-VSX) in the Adjuncts column.
If a digital data or video station will be connected to the jack, and the
equipment supports 2B Data (such as a videoconferencing system
using a BRI interface or a v.35 interface and an ISDN terminal
adapter that supports 2B Data), check the box in the 2B column.
NOTE:
Do not connect equipment that does not support 2B Data (such as
G4 FAX, or a videoconferencing system using a v.35 interface and
an ISDN terminal adapter that does not support 2B Data) to an MLX
jack configured as a 2B Data port.
If an MLX telephone will be connected to a desktop video system in
a passive bus configuration, check the box in the Pass. Bus column.
Also make an entry on Form 4d, MLX Telephone, to indicate that the
MLX telephone is in a passive bus configuration and note the type of
endpoint to which the MLX telephone is connected.
If a digital data or video system is connected to the jack, enter the
extension number in the MLX Telephone Ext. No. column.
Issue 1
February 1998
Page 2-24
