MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
5
Data Communications
Planning Overview
Table 5-3.
System Forms
To Plan
Extension jack connections*
modem data stations
ISDN terminal adapter data stations
local host computer connections
LAN workstation access connections
modem/ISDN terminal adapter pools*
Line/Trunk assignments
Feature assignment
Dial-out code (Hybrid/PBX only)
ARS Facility Restriction Level
(Hybrid/PBX only)
Data hunt groups
*
You must make an entry for extension jack connections.
Form Needed
2a, System Numbering: Extension Jacks (for
all configurations)
2a, System Numbering: Extension Jacks
2b, System Numbering: Digital Adjuncts
2c, System Numbering: Line/Trunk Jacks
2a, System Numbering: Extension Jacks
2b, System Numbering: Digital Adjuncts
4d, MLX Telephones
4b, Analog Multiline Telephone
4e, MFM Adjunct: MLX Telephone
5b, Direct-Line Console (DLC): Digital
5c, MFM Adjunct: DLC
2c, System Numbering: Line/Trunk Jacks
3f, Automatic Route Selection Tables
3g, Automatic Route Selection Default and
Special Numbers Table
2c, System Numbering: Line/Trunk Jacks
2d, System Numbering: Special Renumbers
7d, Group Calling
Issue 1
February 1998
Page 5-21
