MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
3
Lines/Trunks

Assigning Lines/Trunks

Assigning Lines/Trunks
This section contains instructions for assigning lines/trunks to telephones and
Direct-Line Consoles.
NOTE:
NOTE:
NOTE:
To assign lines/trunks to data-only stations, follow the instructions in
Chapter 5, "Data Communications."
Forms Needed
Form 2a, System Numbering: Extension Jacks
Form 2b, System Numbering: Digital Adjuncts
Use the following forms as appropriate for telephones and consoles in the
system. Make one copy of the appropriate form for each extension.
— Form 4b, Analog Multiline Telephone
— Form 4d, MLX Telephone
— Form 4e, MFM Adjunct: MLX Telephone
— Form 4f, Tip/Ring Equipment
— Form 5a, Direct-Line Console (DLC): Analog
— Form 5b, Direct-Line Console (DLC): Digital
— Form 5c, MFM Adjunct: DLC
Planning Form Instructions
1.
On page 1 of Forms 4b, 4d, 5a, and 5b, transfer the following user
information from Form 2a, System Numbering: Extension Jacks to each
copy of each of these telephone forms:
a.
b.
c.
Write the logical ID in the Logical ID space.
Write the extension number in the Extension No. space.
Write the name of the person or the location of the equipment in the
Person or Location space.
3
Issue 1
February 1998
Page 3-52
