MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
3 Lines/Trunks
Selecting Line/Trunk Options
service, proceed to the "Tie Trunks" section after completing these instructions. If
you are planning to use T1 service as PRI trunks in a private network, check the
PRI box under Type of Service on Form 3b (page 1) and proceed to the "PRI
Service" section. Contact the Network Engineering Group for assistance and see
the Network Reference for more information regarding configuration for use in a
private network.
Planning Form Instructions
On Form 3b (page 1), Incoming Trunks: DS1 Connectivity (100D Module), for
each 100D module in the system:
1. In the Module Slot No. space, write the number of the control unit slot that
contains the module (see the Control Unit Diagram on Form 1).
2. Under Type of Service, check T1 (the factory-setting).
NOTES:
1. For T1 or T1 Switched 56 service, the T1 box must be checked on the
form. (If you leave this blank, and T1 is not specified during programming,
the 100D module will not be programmed.)
2. Steps 3, 4, 5, and 6 must match the service provider settings. Check with
the provider if necessary. See "Obtaining Telephone Company
Information," in Chapter 1, for more information.
3. In the table under the T1 Trunks heading, write the channel number(s) for
each trunk type and/or, for Tie or All Tie, check the Tie-PBX, Toll, or S56
boxes.
4. Under the Frame Format heading, do one of the following:
a.
b.
5. Under the Suppression (Line Code) heading, do one of the following:
a.
b.
NOTE:
If more than one 100D module is used, complete the first box,
Module 1, to show the options assigned to the 100D module in the
lowest number control unit slot. Use the second box for the second
lowest-numbered slot, and the last box for the highest-numbered
slot.
To retain the factory setting, check D4 Compatible.
To change the factory setting, check Extended Superframe (ESF).
To retain the factory setting, check AMI-ZCS.
To change the factory setting, check B8ZS.
Issue 1
February 1998
Page 3-25
3
