Factory-Set Assignment, Mlx Telephones (Key And Behind Switch Modes) - Lucent Technologies MERLIN LEGEND Release 6.0 System Planning Manual

MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
3 Lines/Trunks
Assigning Telephone Buttons
22
21
5
4
3
2 Icom
Voice
1 Icom
Ring
MLX-10 or ML X-10DP
Key Mode:
Up to 8 personal line
buttons are assigned
beginning with button 3.
Figure 3-4.

Factory-Set Assignment, MLX Telephones (Key and Behind Switch Modes)

26
24
23 25
15
10
9 14
8 13
7 12
11
6
Behind Switch Mode:
One prime line button
is assigned to button 3.
Issue 1
February 1998
Page 3-60
