4 Features
Group-Assigned Features
4. On Form 7c:
a.
b.
c.
NOTES:
1. If you have not yet created calling groups, you must defer naming them as
receivers until later.
2. If the system includes a voice mail system, see that system's
documentation for completing the receivers.
5. On each copy of Forms 4b, 4d, 5a and 5b that describes a specific
receiver:
a.
b.
6. If designating the QCC Queue as a receiver (Hybrid/PBX mode only), on
the Group Coverage Calls table on Form 6a (page 2):
a.
b.
Write the group number in the Group No. space. Start with
number the groups sequentially.
NOTE:
If a group is the coverage group for AUDIX Voice Power (the factory
setting is Group No. 30 but can be changed), write
group number and list the extensions of AUDIX Voice Power
subscribers (see Form 2a).
List the extension numbers of all senders in the group in the upper
block (see Form 2a).
List the receivers for the group in the lower block by doing one of the
following:
Designate a calling group as a receiver by checking the
Calling Group box (see Form 7d).
Designate the QCC queue as a receiver (Hybrid/PBX mode
only) by checking the QCC Queue box and/or listing the
extension numbers of all receivers (maximum of eight).
Locate an available button on the Button Diagram.
Write Group Cover and the coverage group number in the space
available.
Write the extension(s) for the QCC operator position(s) to receive
the calls in the QCC Operator to Receive Calls column (see
Form 2a).
Write the level for each coverage group's calls in the QCC Queue
Priority Level column. Assign a value of 1 (highest) through 7
(lowest); the factory setting is 4.
Issue 1
February 1998
Page 4-28
1 and
AUDIX
by the
