Identifying Line/Trunk Jacks

Identifying Line/Trunk Jacks
Identifying line/trunk jacks consists of the following tasks:
1. Determining which line/trunk jack types are available according to the types
of modules in the control unit
2. Matching incoming trunks to the jacks that support them
3. Designating jacks for auxiliary equipment (if any)
This section contains instructions for completing all of these tasks.
Forms Needed
Form 1, System Planning
Form 2c, System Numbering: Line/Trunk Jacks
You also need the local telephone company's line/trunk information.
Module Types and Line/Trunk Jack Types
The line/trunk jack type is determined by the type of module. Table 3 1 lists the
line/trunk jack types and the incoming line/trunk or auxiliary equipment that can be
connected to these jacks.
