5 Data Communications
About Data and Video Communications
Summary of Data Station Configurations
Table 5-1 describes the extension jacks and equipment required for each data
station configuration.
Table 5-1. Data Station Configurations
Type of Data Module and
Station Jack Type
Analog voice and 2 adjacent extension
Modem data jacks on one of the
following analog
modules: 408, 408
GS/LS, or 008
Modem data-only 1 extension jack on
an 008 OPT, 016 or
012 module
MLX voice and 1 extension jack on
Modem data an 008 MLX or 408
GS/LS-MLX module
MLX voice and 1 extension jack on
ISDN terminal an 008 MLX or 408
adapter data GS/LS-MLX module
ISDN terminal 1 extension jack on
adapter data-only an 008 MLX or 408
GS/LS-MLX module
Digital Data/Video 1 extension jack on
an 008 MLX or 408
GS/LS-MLX module
set as a 2B Data port,
or 2 jacks set as 1B
Data ports†
* An analog telephone may be connected.
† A digital data/video station that connects directly to an MLX port using either a BRI interface
or a v.35 interface and an ISDN terminal adapter that supports 2B Data, requires only one
MLX port administered as a 2B Data port. A digital data/video station that connects to an
MLX port using a v.35 interface and an ISDN terminal adapter that does not support
2B Data, requires two 1B Data MLX ports. When using the 008 MLX or 408 GS/LS-MLX
module for digital data or video, you must not use Version 29 of the module.
Telephone GPA or
(for voice) MFM
Analog multiline GPA
telephone (and a
BR-241-B1 bridging
adapter)
None* None
MLX telephone* MFM
MLX telephone None
None None
None None
5
Modem or ISDN
Terminal Adapter
Modem
Modem
Modem
ISDN terminal adapter PC, LAN
ISDN terminal adapter
(if using a 7500B data
module, a 440A4
terminating resistor
adapter is also
required)
None if station is
connected by a BRI
interface. One ISDN
terminal adapter if the
TA supports 2B Data.
Two ISDN terminal
adapters if the TAs
support only 1B Data.
Issue 1
February 1998
Page 5-14
Data
Terminal
PC
PC, LAN
workstation, or
local host
PC, or LAN
workstation
workstation, local
host, or video
conferencing
PC, LAN
workstation, local
host, or video
conferencing
G4 FAX, video
conferencing
