MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
2 Control Unit Configuration
Numbering the System
Planning Form Instructions
On Form 2a, mark the extension jack assignments on the 012, 016, and 008 OPT
modules:
1. In the Jack Type column, make sure B is checked next to the logical ID for
each basic telephone jack.
2. In the Person, Location, or Function column, identify each T/R device by
the users name or location and by type, such as single-line telephone, fax,
modem, or Delay Announcement Unit.
3. If the system includes optional applications, indicate the application on the
appropriate line in the Voice Mail column:
4. If the system has AUDIX Voice Power, also write port in the Voice Mail
column for any logical IDs that are being used for fax ports.
5. For each 016 module, if applicable, indicate the Ringing Frequency for that
016 module. Enter 20-Hz or 25-Hz in the Ring Freq. column for all ports on
the 016 module. When configuring a system in the United States or Can-
ada, generally the 20-Hz setting is applicable. The factory setting is 20-Hz.
Proceed to the next section, Labels.
Labels
This section contains instructions to associate alphanumeric labels with extension
numbers so that both the name of the caller and the extension number appear on
display telephones.
Planning Form Instructions
On the appropriate line in the Label column on Form 2a, write the label
(maximum: 7 characters) to be displayed for each telephone.
Proceed to the next section, System Renumbering.
To indicate MERLIN MAIL voice messaging system, write Mail.
To indicate Lucent Technologies Attendant, write Lucent A.
To indicate AUDIX Voice Power IS II or IS III, write AVP.
To indicate Integrated Voice Power Automated Attendant-IS II, write
IVP-AA.
To indicate MERLIN LEGEND Mail, write ML Mail.
To indicate no voice messaging service, write None.
2
Issue 1
February 1998
Page 2-30
