3 Lines/Trunks
Selecting Line/Trunk Options
NOTES:
1. If the system will have two blocks, make a copy of Form 3d and write the
block number in the Block Number space. Check with the local telephone
company to determine the number of digits sent.
2. DID trunks cannot be assigned to ring into a DGC group.
3. If the system uses a combination of DID and non-DID extensions, it is
recommended that two non-local UDP ranges be administered (one for
the DID extensions and one for the non-DID extensions).
Planning Form Instructions
On Form 3d, under the Type heading, do one of the following:
1.
2. Under the Expected Digits heading on Form 3d, do one of the following:
3. Compare the number of digits sent by the local telephone company to the
number of digits in the system numbering plan, and do one of the following:
Under the Signaling heading, do one of the following:
4.
To keep the factory setting, check the Wink-Start box.
To change the type, check the Immediate-Start box.
To show that the telephone company sends the factory-set number
of digits, check the box labeled 3 .
To show the number of digits sent by the telephone company, check
one of the boxes labeled 1 , 2 , or 4 .
If the system's numbering plan matches the number of digits sent by
the telephone company, check 0 (the factory setting) under the
Delete Digits and Add Digits headings.
If the number of digits sent by the local telephone company is more
than the number of digits in the system numbering plan, specify that
one to four digits be deleted from the telephone company digits by
checking the appropriate number (1, 2, 3, or 4) under the Delete
Digits heading.
If the number of digits sent by the local telephone company is fewer
than the number of digits in the system's numbering plan, specify
the specific digits (1 9999) to be added to the digits sent; check the
Add these digits box under the Add Digits heading and then write
the specific digits to be added in the space provided.
To keep the factory-set signal, check Rotary.
To change the setting, check Touch-Tone. (You cannot have
touch-tone if you selected Immediate-Start.)
