MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
5 Data Communications
About Data and Video Communications

MLX Voice and Modem Data

This type of analog data station includes an MLX telephone in addition to the DTE
and modem (see
the T/R interface of the Multi-Function Module (MFM), which is installed in the
MLX telephone. The telephone connects to the control unit through an MLX
extension jack. The communication capabilities of the MLX telephone and data
station can be used simultaneously.
DTE
Optical
Scanner
Fax
Credit Card
Verification
PC Terminal
Host
Computer
Figure 5-3. MLX Voice and Modem Data
Figure 5-3). The modem connects to the MLX telephone through
Data Station
DCE
Digital
Signal
Modem
Home
Menu
T/R
v Volume v
Feature Transfer
HFAI Conf
Mute Drop
Speaker Hold
MLX Telephone/
with Multi-Function
Module (MFM)
5
MERLIN
LEGEND
Control
Unit
Analog
Signal
MLX-20L
More
Inspct
Digital
Message
ABC DEF
1 2 3
MNO
GHI JKL
4 5 6
PQRS TUV WXYZ
7 8 9
OPER #
* 0 Signal
Issue 1
February 1998
Page 5-10
Analog or Tip/Ring
Extension Jack
MLX
Extension Jack
