MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
3 Lines/Trunks
Selecting Line/Trunk Options
Planning Form Instructions
At the top of Form 2c, under the Loop-Start Reliable Disconnect heading, choose
one of the following:
If the loop-start trunks have an unreliable disconnect signal, check the No
box (the factory setting).
If the loop-start trunks have a reliable disconnect signal, check Yes.
NOTE: NOTE: NOTE:
If the system has AUDIX Voice Power/Fax Attendant System, Integrated
Administration automatically sets Loop-Start Reliable Disconnect to Yes.
Outmode Signaling
The system is factory-set to generate touch-tone signals when users dial outside
calls. Identify any rotary-dial trunks that are connected to the system so that
rotary-dial signals can be used for these trunks.
NOTE: NOTE: NOTE:
Touch-tone, single-line telephone users cannot make calls using rotary-dial
trunks unless their phones allow them to switch between touch tones and
rotary dial pulses. Check with the local or long-distance telephone company
to determine which, if any, trunks connected to the system are rotary-dial
trunks.
Planning Form Instructions
In the Outmode Signaling column on Form 2c, do one of the following:
For touch-tone trunks (factory setting), put a check in the TT column.
For rotary-dial trunks, put a check in the R column.
