MERLIN LEGEND Communications System Release 6.0
System Planning 555-660-112
1 Before You Begin
Requirements for Supporting CTI Applications
Incoming/Outgoing
Calls
Public
Network
Figure 1-1. System Configuration for Support of CTI Applications
For this configuration you must have the equipment and software below:
An Intel i386, Intel i486, or Pentium Class computer with at least 16
megabytes of RAM. Additional memory may be needed if additional
applications will be running on the server machine. Refer to the MERLIN
LEGEND Network Manager's Guide form more information.
NetWare Version 3.12, 4.1 or 4.11.
5 megabytes of disk space available on the SYS (system) volume
Telephony Services for NetWare software, Release 2.2.1 or later, installed
An Eicon/G. Diehl SCOM card for the CTI link
A free 8- or 16-bit ISA slot for the Eicon/G. Diehl SCOM card
System software Release 5.0 or later installed on the MERLIN LEGEND
Communications System
The MERLIN LEGEND Communications System configured in Hybrid/PBX
mode
An MLX port board (using firmware version 28 or later, except Version 29)
installed in the MERLIN LEGEND Communications System
NOTE: NOTE: NOTE:
If you have Version 29, replace the board with an appropriate version, or for
a replacement card, call the TSO at: 1 800 628-2888.
MERLIN LEGEND
Release 5.0 or later
Telephony Server
Telephony Server
CTI Link CTI Link
LAN
LAN
Client Desktop
Client Desktop
Issue 1
February 1998
Page 1-7
